Guides

CC Managing Campaign Records

How to add and remove/delete records from Dynamic Campaigns

Suggest Edits

TODO

📘

Prerequisites

  • The Campaign MUST be configured as a Dynamic Campaign
  • Records MUST exist in the CC CRM to be added to a campaign.

Overview

The 8x8 Contact Center Dynamic Campaigns API can be used to accomplish one or more of the following.

  • Adds and removes records from an active campaign
  • Sends records to a specified campaign via the API
  • Adds records to a live campaign
  • Removes records from a campaign so they are not dialed again
  • Schedules a call with a possible maximum of 7 days in advance
  • Uploads for a maximum of 5 million records

Authentication

CC Campaign APIs leverage the credentials from the Integration >> API Token area in Configuration Manager.
These APIs use Basic Authentication.
The username will be the "Username" value from this screen, it is generally the tenant name
The Data Request Token will the password
Authorization :Basic encodedValue
Where encodedValue is base64encode(username:password)

Working with Campaign Records

Add Records to Campaign

Parameters

Method: POST

Headers

NameRequiredDescriptionExample
Authorization✓Basic Authentication where username is the value of username and the password is the value of Action Request Token.Basic bXljbGllbnRJZDpuZXZlcnRlbGxhbnlvbmU=
Content-Type✓Set content type for body to application/jsonapplication/json

Path

NameRequiredDescriptionExample
ccPlatform✓Contact Center platform can be found in the url when accessing CC Configuration Manager.
North America starts NA
Europe starts EU
Canada starts CA
Asia Pacific starts AP
Australia starts AU
Bell Canada starts BC
Sandbox starts SB		na12
campaignId✓The id of the campaign to get the status for. Can be located in CC Configuration Manager "Campaigns" and adding the "Campaign ID" column, or within a specific campaign as part of "Properties", "General Properties"125

Body

Body is an unnamed array of customer records. See Add Campaign Record Request for a full example.

Customer Record:

NameRequiredDescriptionExample
customer-id✓customer-id is the ACCOUNTNUM of the customer from the CC CRM.
This can be found in the Agent Workspace OR via the CC CRM API.		10003629
schedule-date-time☐Optional, scheduled/desired time for call which will influence the time the record is processed. ISO8601 datetime format."2022-08-29T09:00:00.000Z"

Add Campaign Record Request

curl --location --request POST 'https://vcc-{ccPlatform}.8x8.com/api/tstats/campaigns/{campaignId}/customers' \
--header 'Content-Type: application/json' \
--header 'Authorization: Basic {encodedValue}'
--data-raw '[
  {
    "customer-id": 10003629,  "schedule-date-time": "2022-07-14T09:00:00.000Z"
  },
  {
    "customer-id": 10003621,  "schedule-date-time": "2022-07-14T09:00:00.000Z"
  }
]'

Add Campaign Record Response (showing additional responses)

Response is HTTP 207 Multi-Status response. Each Customer has it's own status represented.

[
  {
    "customer-id": 10003629,
    "schedule-date-time": "2016-08-29T09:00:00.000Z",
    "http-status": 200
  },
  {
    "customer-id": 1000001,
    "http-status": 200
  },
  {
    "customer-id": 10003621,
    "http-status": 400,
    "message": "Duplicate customer"
  },
  {
    "customer-id": 1000777,
    "schedule-date-time": "2016-08-29T     09:00:00.000Z",
    "http-status": 400,
    "message": "Invalid schedule-date-time format - please use ISO 8601 format"
  },
  {
    "customer-id": null,
    "http-status": 400,
    "message": "Invalid customer-id"
  },
  {
    "customer-id": 9,
    "http-status": 404,
    "message": "The customer-id has not been found."
  },
  {
    "customer-id": 10000,
    "schedule-date-time": "2016-08-29T09:00:00.000Z",
    "http-status": 400,
    "message": "The subject schedule-date-time is in the past."
  },
  {
    "customer-id": 1000778,
    "schedule-date-time": "2016-08-29T09:00:00.000Z",
    "http-status": 400,
    "message": "The subject schedule-date-time is outside the campaign schedule from 2016-08-27T09:00:00.000Z to 2016-08-28T09:00:00.000Z."
  },
  {
    "customer-id": 100002,
    "schedule-date-time": "2016-08-29T09:00:00.000Z",
    "http-status": 400,
    "message": "The subject schedule-date-time must be within 7 days ahead of a future period."
  }
]

View Records in Campaign

Parameters

Method: GET

Headers

NameRequiredDescriptionExample
Authorization✓Basic Authentication where username is the value of username and the password is the value of Data Request Token.Basic bXljbGllbnRJZDpuZXZlcnRlbGxhbnlvbmU=

Path

NameRequiredDescriptionExample
ccPlatform✓Contact Center platform can be found in the url when accessing CC Configuration Manager.
North America starts NA
Europe starts EU
Canada starts CA
Asia Pacific starts AP
Australia starts AU
Bell Canada starts BC
Sandbox starts SB		na12
campaignId✓The id of the campaign to get the status for. Can be located in CC Configuration Manager "Campaigns" and adding the "Campaign ID" column, or within a specific campaign as part of "Properties", "General Properties"125

View Campaign Records Request

curl --location --request GET 'https://vcc-{ccPlatform}.8x8.com/api/stats/campaigns/{campaignId}/records.json' \
--header 'Authorization: Basic {encodedValue}'

View Campaign Record Response

The success response code is HTTP 200. Each Record will have its own status and information.

{
	"records": {
		"record": [
			{
				"campaign-name": "BOC Admin Demo",
				"campaign-id": 1,
				"record-id": 10000000,
				"phone-list": "*Phone Number|5551234567",
				"status": 3,
				"status-code": 0,
				"ext-trans-data": "",
				"disposition-code": 1002
			},
			{
				"campaign-name": "BOC Admin Demo",
				"campaign-id": 1,
				"record-id": 10000001,
				"phone-list": "*Phone Number|5557654321",
				"status": 3,
				"status-code": 0,
				"ext-trans-data": "",
				"disposition-code": 1002
			}
		]
	}
}

There are several predefined values

Record status:

0 = New
1 = Queued
2 = Accepted
3 = Completed
4 = Scheduled

Status code:

0 = Default
1 = Max Attempt Reached
2 = Skipped
3 = No Phone Number
4 = Invalid Phone Number

Disposition code:

1000 = None
1001 = Try Again
1002 = Scheduled Call Back

Delete Record from Campaign

Parameters

Method: DELETE

Headers

NameRequiredDescriptionExample
Authorization✓Basic Authentication where username is the value of username and the password is the value of Data Request Token.Basic bXljbGllbnRJZDpuZXZlcnRlbGxhbnlvbmU=

Path

NameRequiredDescriptionExample
ccPlatform✓Contact Center platform can be found in the url when accessing CC Configuration Manager.
North America starts NA
Europe starts EU
Canada starts CA
Asia Pacific starts AP
Australia starts AU
Bell Canada starts BC
Sandbox starts SB		na12
campaignId✓The id of the campaign to get the status for. Can be located in CC Configuration Manager "Campaigns" and adding the "Campaign ID" column, or within a specific campaign as part of "Properties", "General Properties"125
customerId✓customer-id is the ACCOUNTNUM of the customer from the CC CRM.
This can be found in the Agent Workspace OR via the CC CRM API.		10003629

Delete Campaign Record Request

curl --location --request DELETE 'https://vcc-{ccPlatform}.8x8.com/api/tstats/campaigns/{campaignId}/customers/{customerId}' \
--header 'Authorization: Basic {encodedValue}'

Delete Campaign Record Response

The success response code is HTTP 204 (No Content)

Updated over 1 year ago
